Hedson IRT 4-1 PCAuto Curing Lamp

Product Description

Hedson IRT 4-1 PcAuto Curing Lamp - most complete mobile dryers with the highest output and capacity. The products are easy to use and the curing times are reduced to a minimum. One compact cassette. Each cassette is composed of 4 IRT short wave lamps and a cooling ventilator. The lamps are fixed in gold coated FreeForm reflector bodies for optimal heat distribution. Features include: automatic temperature control of the drying surface, automatic distance indication and laser sight guide for correct alignment over the repair area.

Unique possibilities to position the cassettes Gold-coated FreeForm reflectors for optimal heat distribution Computerised monitoring of curing Pyrometer for exact temperature control Laser circle indicates where temperature measuring takes place Electronic distance sensor Very easy to use with 12 preset and 3 custom programs Can cure all paint materials Smart stand design Efficient particle filter on the cassettes Powerful ventilation that cools the cassette and increases lamp life Maximum cassette height 81.5" (horizontal), 100.5" mm (vertical)

Hedson IRT Catalog Link

Cure area - 43.5" x 59" Minimum Distance from Panel - 600mm (24") Power Rating - 6 kW Electrical specifications - 220 Volts, 60Hz, Single Phase, 26A 220 Volts, 60Hz, Three Phase, 16A 480 Volts, 60Hz, Three Phase, 9A
