DeFelsko DEF-200-B1-MGM Positector Paint & Coating Thickness Gauge for Plastic & Non-Metal Surfaces
The DeFelsko PosiTector DEF-200-B1-MGM Standard Ultrasonic Coating Thickness Gage Kit includes everything needed for testing, This is a compliant with most Collision repair programs, and is approved for the GM & Mercedes Program.
Non-destructively measures a wide variety of applications using proven ultrasound technology. Measure coating thickness over wood, concrete, plastic, and more. Advanced models measure up to 3 layers with graphics.
This plastic system has the following Features:
- Compliant for GM, Mercedes, Ford, Honda, and many other repair Programs
- Tool will accurately measure paint thickness and ensure proper ADAS requirement
- Ready to measure—no adjustment required for most applications.
- Larger 2.8" impact resistant color touchscreen and a quick menu navigation.
- Auto rotating display with Flip Lock.
- On-gage help explains menu items at the touch of a button.
- Easy RESET feature restores factory settings.
- Certificate of Calibration showing traceability to NIST or PTB included
- Proven non-destructive ultrasonic technique conforms to ASTM D6132 and ISO 2808
- Weatherproof, dustproof, and water resistant—IP65-rated enclosure
- Ergonomic design with durable rubberized grip
- Shock-absorbing, protective rubber holster for added impact resistance.
- PosiTector body accepts all PosiTector 200, 6000, DPM, IRT, RTR, SPG, SST, SHD, BHI, and UTG probes easily converting from a coating thickness gage to a dew point meter, surface profile gage, soluble salt tester, hardness tester, or ultrasonic wall thickness gage.
- Mils/Microns switchable
- Selectable display languages.
- Max Thick Mode displays the deepest ultrasonic echo eliminating the need to adjust the Lo Range—ideal for ignoring unwanted surface echos
- Screen Capture – save 100 screen images for record keeping and review.
- USB port for fast, simple connection to a PC and to supply continuous power. USB cable included.
- PosiSoft USB Drive—stored readings and graphs can be accessed using universal PC/Mac web browsers No software
- Includes PosiSoft suite of software for viewing and reporting data.
- Software Updates via web keep your gage current.
- Includes a 2 Year manufactures warranty
