Product Description
Overview
Special Features:
- The strongest aluminum alloys are used and heat-treated to provide the maximum combination of strength to resist fractures.
- Lightweight aluminum reservoir for portability.
- The best choice for applications where composite reservoirs may not be suitable.
- Large oil capacity to power a wide range of cylinders.
- Two-speed pumps provide rapid cylinder’s stroke at 1st stage, minimizing effort. At the 2nd stage, the pumps automatically switch when a load is applied. This allows for faster fills and reduces cycle times for many testing operations
Speed | 2 |
---|---|
Port Size (NPT) | 3/8" |
Usable Oil Capacity (in³) | 80 |
Pressure Rating - 1st Stage (psi) | 300 |
Pressure Rating - 2nd Stage (psi) | 10000 |
Oil Displacement Per Stroke - 1st Stage (in³) | 0.345 |
Oil Displacement Per Stroke - 2nd Stage (in³) | 0.134 |
Max Handle Effort (lbs) | 92.4 |
Piston Stroke (in) | 1.00 |
Weight (lbs) | 18.000000 |
